Stabilizer

Applications

Inclined and Horizontal Wells: Xiongchen centralizer can effectively reduce the starting force and running force to ensure that the casing pipe is successfully lowered to the bottom of the well
Small and Irregular Boreholes: The bow piece of Xiongchen centralizer has good elasticity and stability, which ensures that the casing pipe can safely pass through various complicated boreholes, such as reduction, J-type, S-type, etc.
Oil Formation Segment: Laboratory and field application data show that 80-90% casing centering must be ensured to achieve good cementing effect, especially for horizontal well cementing. The use of the integrated centralizer with excellent performance can effectively enhance the well cementing quality of the oil formation segment

Question

Why Polycrystalline diamond compact (PDC) bearings?

Abrasive particles, high temperatures, corrosive chemicals, and high loads can all contribute to a failure in rotating equipment.
PDC bearings improve overall bearing reliability in harsh conditions while eliminating the need for seals.
PDC is not a diamond coating, but instead it is a thick, manmade diamond surface that is ideally suited for operation in process fluids
where abrasive particles, like sand, can cause accelerated wear and failure with traditional bearing materials.

The Advantages of PDC:
High thermal conductivity: The PDC material reduces the local limit temperatures that lead to bearing degradation and prevents damage to the bearing material caused by the high heat .
High load: They can operate effectively over a wide range of speeds and loads. For example, in some oil and gas drilling, diamond bearings can operate at loads of up to 60,000 pounds at 100-6,000 rpm.
Wear-resistance and high temperature resistance: The PDC material has an extremely low coefficient of friction (coefficient of friction between 0.01 and 0.03). It can operate at high temperatures (up to 233℃).
High fracture toughness: Bearing materials with excellent fracture toughness reduce the likelihood of damage caused by shock loads.
High corrosion resistance: They can be unaffected by corrosive substances in the application environment.
Simplicity: There is no need for specialized lubrication during use, simplifying equipment and components by eliminating the need for seals and separate lubrication systems.
Long life: The service life is more than 6 times longer than that of tungsten carbide bearings.

Because of its extreme hardness, PDC is ideally suited to resist wear from abrasive particles inlubricants and process fluids.
